FEATURES & BENEFITS
• Compressor Type: Scroll
• BTU Rating: 36,000
• Refrigerant: R410A
• Connection Type: Molded Plug (Not Included)
• Oil: POE (Polyol Ester)
• Voltage: 208/230Vac
• Single Phase
• Capacitor Rating: 45/370µF
• MCC: 28
• LRA: 112
• RLA: 20
• Hertz: 60
• Suction Line Size: 7/8″
• Suction Line Height: 11.5″
• Discharge Line Size: 1/2″
• Discharge Line Height: 15.34″
| Electrical | |
|---|---|
| Hertz | 60 |
| Phase | 1 |
| RLA | 20 |
| Voltage | 208/230 |
| Specification | |
|---|---|
| BTU Rating | 36 to 40kBTU |
| Oil | POE (Polyester) |
| Suction Line Height | 11.50″ |
| Discharge Line Height | 15.34″ |
| Discharge Line Size | 1/2″ |
| BTU Output | 36000 |
| Compressor Type | Scroll |
| Refrigerant | R-410A |
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 70.45 |
| Exterior Dimensions (D) (inches) | 9.400000 |
| Exterior Dimensions (W) (inches) | 8.000000 |
| Exterior Dimensions (H) (inches) | 16.300000 |
| Shipping Weight (lbs) | 100.000000 |
| Warranty | |
|---|---|
| Country of Origin | United States |
- TypeScroll Compressor
- VendorCopeland
- Saber’sItem 41223582 | Model ZP36K5E-PFV-830
- Weight75 lb
- Color/FinishBlack
- ReturnableNon-Returnable
- Saber Sales ExclusiveNo
- CA Residents Prop 65 Warning(s)Yes
