Ace Pumps Discharge Pumps
Ace Pumps began to develop hydraulic driven motor pumps in 1969 and hasn’t looked back since. They are a industry leader for various pump application throughout the agriculture industry due to their mounting versatility, customized performance, and easy maintenance. Listed below are just 6 of the different selections of centrifugal hydraulic pumps that we offer from Ace Pumps.
Here are the main features for the FMC-150-HYD-206(49920):
- For applications with large tanks and longer spray booms
- Higher Pressure
- Greater Volume
- “F” model is equipped with both NPT Ports and Standard Flanged Connections
The 206 hydraulic motor fits almost any type of hydraulic system on your tractor or sprayer. It requires a 7 GPM maximum hydraulic fluid input. These pumps are recommended for the following applications:
- Load Sense Closed Center
- Open Center (up to 16 GPM w/internal bypass)
- Pressure Comp Closed Center
The FMC-150F-HYD-206(49942) also features:
- 1½” Suction x 1¼” Discharge
- 120 PSI
- 5100 RPM
- 135 GPM
- 7 GPM Hydraulic Motor
Ace Pumps Part
49942 = 1½” Suction x 1¼”; Flanged
